建筑工地工人追踪

LoRaWAN
头盔追踪器传感器

Lansitec LoRaWAN Helmet Sensor is designed based on GNSS, Bluetooth5.0 and LoRaWAN technology. It supports 室内和室外追踪.

It supports various features which contribute to easy management in industrial settings. Its built-in 3-axis accelerator could be used for determining the motion status of the terminal. Therefore, it can help save battery and enhance user experience.

Helmet Sensor is suitable for the following use cases:

  • Visitor Management
  • Factory Worker Tracking
  • Construction Worker Tracking,
  • Vehicle Tracking etc.
头盔追踪器

Helmet Tracker Specifications

连接

蓝牙协议

Bluetooth 5.0, iBeacon

蓝牙发射功率

-20 to +4 dBm TX power, configurable in 4dB steps

蓝牙灵敏度

-96dBm

Bluetooth Positioning Accuracy

3 分钟

LoRaWAN 协议

LoRaWAN 1.0.2B, Class A

Activation Mode

OTAA or ABP

LoRaWAN 频段

US915、AU915、EU868、EU433、AS923、RU864、KR920、IN865、CN470

LoRa TX Power

0 to 20dBm

LoRa 灵敏度

-139dBm @SF12, 带宽125kHz, 434MHz/470MHz -137dBm @SF12, 带宽125kHz, 868MHz/915MHz

LoRa距离

> 1km in urban area

加密

AES128

GNSS Band

GPS, BDS, GALILEO, GLONASS, QZSS, SBAS (WAAS, EGNOS, GAGAN, MSAS)

GNSS Tracking Accuracy

2.5m

GNSS Cold Start Duration

30s to 120s

机制

方面

80*80*35mm

工作温度

-10℃~+65℃

充电温度

0°C~+50°C

存储温度

-20℃~+80℃

工作湿度

5% ~ 95% (无凝结)

重量

90g

Housing Material

ABS and PC

防护等级

IP66

Impact Protection

IK10

功能

G-sensor

支持

Barometer

Support, 10cm altitude accuracy

PCB 涂层

防水涂料

NFC Tag (optional)

1KB

可调整位置报告间隔

5s x n (0 to 65535)

心跳报告间隔

30s x n (1 to 255)

转变

Touch button x2

通过蓝牙进行 FOTA

支持

Battery Level Report

支持

Proximity Detection

支持

通过蓝牙进行资产管理

Report nearby Bluetooth beacons/tags to a LoRaWAN gateway

力量

电池

Li-ion rechargeable battery, 1200mAh

GNSS (report interval >10minutes)

Approx. 8,000 times

Bluetooth positioning

Approx. 33,000 times

待机电流

25μA

Maximum Current

145mA
