LoRaWAN

SocketSync
Bluetooth Gateway

Streamline your indoor tracking and data collection with the Lansitec SocketSync Bluetooth Gateway. Built on a powerful combination of BLE and LoRaWAN technology, this compact device reads Bluetooth beacon data—such as location or sensor measurements—and forwards it securely via LoRaWAN to your preferred server or cloud platform. Designed for easy installation in office buildings, hospitals, or public venues, the SocketSync Gateway features adjustable parameters—including heartbeat intervals and LoRaWAN work modes—so you can tailor its operation to your specific needs. Whether you’re tracking hospital equipment, monitoring staff movement, or managing public spaces, SocketSync offers a flexible, cost-efficient gateway solution with minimal downtime.

Features

What Makes it Unique

Plug-and-Play Installation Simply connect the gateway to an AC power source (85–305VAC). A built-in 300mAh battery ensures continuous operation during power outages.
Bluetooth 5.0 & LoRaWAN Integration Receive data from BLE beacons and transmit it over LoRaWAN for broad coverage without incurring additional data costs.
Adjustable Reporting & Alarms Customize heartbeat intervals, position reports, and alarm triggers for precise control over your monitoring systems.
Long-Distance LoRa Communication Achieve up to 1.5km coverage in urban areas, enabling wide-area indoor or near-indoor tracking.

Configurable Bluetooth Payload Filter out unnecessary data bytes from BLE sensor messages to optimize bandwidth and power usage.
Robust Security Utilize AES128 encryption for safe, end-to-end data transmission and peace of mind in secure environments.
Versatile Sensor Compatibility Collect temperature, humidity, pressure, and more from BLE sensors, with the option to tailor data reports to your unique application. Wide power supply - 85~305VAC

Use Cases

Where it Could be Used for

Hospital Asset Tracking

Monitor crucial medical tools—like infusion pumps and diagnostic devices—and ensure they’re located, maintained, and deployed efficiently.

Public Space Management

Oversee security personnel, maintenance teams, or event staff in large venues such as shopping malls, stadiums, or airports. Real-time location visibility improves safety and responsiveness.

Warehouse & Inventory Optimization

Track pallets, forklifts, or valuable goods within a busy warehouse environment. Leverage the gateway’s long-range connectivity to reduce misplaced items and streamline operations.

Smart Office & Co-Working Spaces

Monitor desk occupancy, temperature, and air quality with BLE sensors. Automatically adjust HVAC settings and optimize workspace allocation in real time to boost comfort and efficiency.

Relative articles

More Cases

October 12, 2024

Lansitec Introduces SocketSync Proximity Sensor

December 12, 2024

IoT Smart Solution for Bluetooth Socket Gateway

Technical Details

Product Specifications

Mechanics

Dimension

81*61*26mm (45mm, with the mounting lug)

Operating Temperature

-10 ~ +60°C

Storage Temperature

-45°C ~ +85°C

Operating Humidity

0% ~ 95% (non-condensing)

Housing Material

ABS with fire retardant

Power

Battery

Li-ion rechargeable battery, 300mAh

AC Input

85~305VAC

Standby Current

5mA

Max. Current

200mA

Switch

Mechanical

Status LED

Support

LoRaWAN

Activation Mode

OTAA or ABP

LoRa Frequency

US915, AU915, EU868, EU433, AS923, RU864, ID920, KR920, IN865, KZ865, CN470, CN470-Ali

LoRa TX Power

0 to 20dBm

LoRa Sensitivity

-139dBm @SF12, BW 125kHz, 434MHz/470MHz
-137dBm @SF12, BW 125kHz, 868MHz/915MHz

LoRa Communication Distance

>1.5km in the urban area

Encryption

AES128

Bluetooth

TX Power

4, 0, -4, -8, -12, -16, -20dBm

Sensitivity

-96dBm

Receiving Range

50m

Functions

Adjustable Position Report Interval

5s x n (1 to 65536)

Heartbeat Report Interval

30s x n (1 to 65536)

FOTA over Bluetooth

Support

Adjustable Bluetooth Payload to be reported

Filter any data bytes in a Bluetooth payload and report any via LoRaWAN

Max. Beacons Supported

105*, maximum of 15 beacon messages at one single LoRaWAN package @SF9

* Please reach out to us if more are needed.

Certification

CE, FCC, RCM
